Connecting an LCD to your Raspberry Pi will spice up almost any project, but what if your pins are tied up with connections to other modules? No problem, just connect your LCD with I2C, it only uses two pins (well, four if you count the ground and power).
In this tutorial, I’ll show you everything you need to set up an LCD using I2C, but if you want to learn more about I2C and the details of how it works, check out our article Basics of the I2C Communication Protocol.
There are a couple ways to use I2C to connect an LCD to the Raspberry Pi. The simplest is to get an LCD with an I2C backpack. But the hardcore DIY way is to use a standard HD44780 LCD and connect it to the Pi via a chip called the PCF8574.
The PCF8574 converts the I2C signal sent from the Pi into a parallel signal that can be used by the LCD. Most I2C LCDs use the PCF8574 anyway. I’ll explain how to connect it both ways in a minute.
I’ll also show you how to program the LCD using Python, and provide examples for how to print and position the text, clear the screen, scroll text, print data from a sensor, print the date and time, and print the IP address of your Pi.
If you don’t have an I2C enabled LCD or a PCF8574, these tutorials will show you how to connect an LCD with the GPIO pins:
- How to Setup an LCD on the Raspberry Pi and Program it With C
- How to Setup an LCD on the Raspberry Pi and Program it With Python
Here’s the video version of this tutorial, where I go through the setup and show all of the programming examples below:
Connect the LCD
I2C (inter-integrated circuit) is also known as the two-wire interface since it only uses two wires to send and receive data. Actually it takes four if you count the Vcc and ground wires, but the power could always come from another source.
Connecting an I2C Enabled LCD
Connecting an LCD with an I2C backpack is pretty self-explanatory. Connect the SDA pin on the Pi to the SDA pin on the LCD, and the SCL pin on the Pi to the SCL pin on the LCD. The ground and Vcc pins will also need to be connected. Most LCDs can operate with 3.3V, but they’re meant to be run on 5V, so connect it to the 5V pin of the Pi if possible.
Connecting an LCD With a PCF8574
If you have an LCD without I2C and have a PCF8574 chip lying around, you can use it to connect your LCD with a little extra wiring. The PCF8574 is an 8 bit I/O expander which converts a parallel signal into I2C and vice-versa. The Raspberry Pi sends data to the PCF8574 via I2C. The PCF8574 then converts the I2C signal into a 4 bit parallel signal, which is relayed to the LCD.
Use the following diagram to connect the LCD to the Raspberry Pi via the PCF8574:
- R1: 10K Ohm resistor
- Potentiometers: 10K Ohms, but can be substituted with 1K to 3K Ohm resistors
In the diagram above, the blue wire connects to the Raspberry Pi’s SDA pin. The yellow wire connects to the Pi’s SCL pin.
Enable I2C on the Pi
Before we get into the programming, we need to make sure the I2C module is enabled on the Pi and install a couple tools that will make it easier to use I2C.
Enable I2C in raspi-config
First, log in to your Pi and enter
sudo raspi-config to access the configuration menu. Then arrow down and select “Advanced Settings”:
Now arrow down and select “I2C Enable/Disable automatic loading”:
Choose “Yes” at the next prompt, exit the configuration menu, and reboot the Pi to activate the settings.
Install I2C-tools and SMBUS
Now we need to install a program called I2C-tools, which will tell us the I2C address of the LCD when it’s connected to the Pi. So at the command prompt, enter
sudo apt-get install i2c-tools.
Next we need to install SMBUS, which gives the Python library we’re going to use access to the I2C bus on the Pi. At the command prompt, enter
sudo apt-get install python-smbus.
Now reboot the Pi and log in again. With your LCD connected, enter
i2cdetect -y 1 at the command prompt. This will show you a table of addresses for each I2C device connected to your Pi:
The I2C address of my LCD is 21. Take note of this number, we’ll need it later.
Programming the LCD
We’ll be using Python to program the LCD, so if this is your first time writing/running a Python program, you may want to check out How to Write and Run a Python Program on the Raspberry Pi before proceeding.
Installing the Library
Copy this code for the library, then save it in a file named I2C_LCD_driver.py:
# -*- coding: utf-8 -*- # Original code found at: # https://gist.github.com/DenisFromHR/cc863375a6e19dce359d """ Compiled, mashed and generally mutilated 2014-2015 by Denis Pleic Made available under GNU GENERAL PUBLIC LICENSE # Modified Python I2C library for Raspberry Pi # as found on http://www.recantha.co.uk/blog/?p=4849 # Joined existing 'i2c_lib.py' and 'lcddriver.py' into a single library # added bits and pieces from various sources # By DenisFromHR (Denis Pleic) # 2015-02-10, ver 0.1 """ # i2c bus (0 -- original Pi, 1 -- Rev 2 Pi) I2CBUS = 0 # LCD Address ADDRESS = 0x27 import smbus from time import sleep class i2c_device: def __init__(self, addr, port=I2CBUS): self.addr = addr self.bus = smbus.SMBus(port) # Write a single command def write_cmd(self, cmd): self.bus.write_byte(self.addr, cmd) sleep(0.0001) # Write a command and argument def write_cmd_arg(self, cmd, data): self.bus.write_byte_data(self.addr, cmd, data) sleep(0.0001) # Write a block of data def write_block_data(self, cmd, data): self.bus.write_block_data(self.addr, cmd, data) sleep(0.0001) # Read a single byte def read(self): return self.bus.read_byte(self.addr) # Read def read_data(self, cmd): return self.bus.read_byte_data(self.addr, cmd) # Read a block of data def read_block_data(self, cmd): return self.bus.read_block_data(self.addr, cmd) # commands LCD_CLEARDISPLAY = 0x01 LCD_RETURNHOME = 0x02 LCD_ENTRYMODESET = 0x04 LCD_DISPLAYCONTROL = 0x08 LCD_CURSORSHIFT = 0x10 LCD_FUNCTIONSET = 0x20 LCD_SETCGRAMADDR = 0x40 LCD_SETDDRAMADDR = 0x80 # flags for display entry mode LCD_ENTRYRIGHT = 0x00 LCD_ENTRYLEFT = 0x02 LCD_ENTRYSHIFTINCREMENT = 0x01 LCD_ENTRYSHIFTDECREMENT = 0x00 # flags for display on/off control LCD_DISPLAYON = 0x04 LCD_DISPLAYOFF = 0x00 LCD_CURSORON = 0x02 LCD_CURSOROFF = 0x00 LCD_BLINKON = 0x01 LCD_BLINKOFF = 0x00 # flags for display/cursor shift LCD_DISPLAYMOVE = 0x08 LCD_CURSORMOVE = 0x00 LCD_MOVERIGHT = 0x04 LCD_MOVELEFT = 0x00 # flags for function set LCD_8BITMODE = 0x10 LCD_4BITMODE = 0x00 LCD_2LINE = 0x08 LCD_1LINE = 0x00 LCD_5x10DOTS = 0x04 LCD_5x8DOTS = 0x00 # flags for backlight control LCD_BACKLIGHT = 0x08 LCD_NOBACKLIGHT = 0x00 En = 0b00000100 # Enable bit Rw = 0b00000010 # Read/Write bit Rs = 0b00000001 # Register select bit class lcd: #initializes objects and lcd def __init__(self): self.lcd_device = i2c_device(ADDRESS) self.lcd_write(0x03) self.lcd_write(0x03) self.lcd_write(0x03) self.lcd_write(0x02) self.lcd_write(LCD_FUNCTIONSET | LCD_2LINE | LCD_5x8DOTS | LCD_4BITMODE) self.lcd_write(LCD_DISPLAYCONTROL | LCD_DISPLAYON) self.lcd_write(LCD_CLEARDISPLAY) self.lcd_write(LCD_ENTRYMODESET | LCD_ENTRYLEFT) sleep(0.2) # clocks EN to latch command def lcd_strobe(self, data): self.lcd_device.write_cmd(data | En | LCD_BACKLIGHT) sleep(.0005) self.lcd_device.write_cmd(((data & ~En) | LCD_BACKLIGHT)) sleep(.0001) def lcd_write_four_bits(self, data): self.lcd_device.write_cmd(data | LCD_BACKLIGHT) self.lcd_strobe(data) # write a command to lcd def lcd_write(self, cmd, mode=0): self.lcd_write_four_bits(mode | (cmd & 0xF0)) self.lcd_write_four_bits(mode | ((cmd << 4) & 0xF0)) # write a character to lcd (or character rom) 0x09: backlight | RS=DR< # works! def lcd_write_char(self, charvalue, mode=1): self.lcd_write_four_bits(mode | (charvalue & 0xF0)) self.lcd_write_four_bits(mode | ((charvalue << 4) & 0xF0)) # put string function with optional char positioning def lcd_display_string(self, string, line=1, pos=0): if line == 1: pos_new = pos elif line == 2: pos_new = 0x40 + pos elif line == 3: pos_new = 0x14 + pos elif line == 4: pos_new = 0x54 + pos self.lcd_write(0x80 + pos_new) for char in string: self.lcd_write(ord(char), Rs) # clear lcd and set to home def lcd_clear(self): self.lcd_write(LCD_CLEARDISPLAY) self.lcd_write(LCD_RETURNHOME) # define backlight on/off (lcd.backlight(1); off= lcd.backlight(0) def backlight(self, state): # for state, 1 = on, 0 = off if state == 1: self.lcd_device.write_cmd(LCD_BACKLIGHT) elif state == 0: self.lcd_device.write_cmd(LCD_NOBACKLIGHT) # add custom characters (0 - 7) def lcd_load_custom_chars(self, fontdata): self.lcd_write(0x40); for char in fontdata: for line in char: self.lcd_write_char(line)
There are a couple things you may need to change in the code above, depending on your set up. On line 19 there is a function that defines the port for the I2C bus (
I2CBUS = 0). Older Raspberry Pi’s used port 0, but newer models use port 1. So depending on which RPi model you have, you might need to change this from 0 to 1.
Next, put the I2C address of your LCD in line 22 of the library code. For example, my I2C address is 21, so I’ll change line 22 to
ADDRESS = 0x21.
Write to the Display
The following is a bare minimum “Hello World!” program to demonstrate how to initialize the LCD:
import I2C_LCD_driver from time import * mylcd = I2C_LCD_driver.lcd() mylcd.lcd_display_string("Hello World!", 1)
Position the Text
mylcd.lcd_display_string() prints text to the screen and also lets you chose where to position it. The function is used as
mylcd.lcd_display_string("TEXT TO PRINT", ROW, COLUMN). For example, the following code prints “Hello World!” to row 2, column 3:
import I2C_LCD_driver from time import * mylcd = I2C_LCD_driver.lcd() mylcd.lcd_display_string("Hello World!", 2, 3)
On a 16×2 LCD, the rows are numbered 1 – 2, while the columns are numbered 0 – 15. So to print “Hello World!” at the first column of the top row, you would use
mylcd.lcd_display_string("Hello World!", 1, 0).
Clear the Screen
mylcd.lcd_clear() clears the screen:
import I2C_LCD_driver from time import * mylcd = I2C_LCD_driver.lcd() mylcd.lcd_display_string("This is how you", 1) sleep(1) mylcd.lcd_clear() mylcd.lcd_display_string("clear the screen", 1) sleep(1) mylcd.lcd_clear()
We can use a simple while loop with the
mylcd.lcd_clear() functions to create a continuous blinking text effect:
import time import I2C_LCD_driver mylcd = I2C_LCD_driver.lcd() while True: mylcd.lcd_display_string(u"Hello world!") time.sleep(1) mylcd.lcd_clear() time.sleep(1)
You can use the
time.sleep() function on line 7 to change the time (in seconds) the text stays on. The time the text stays off can be changed in the
time.sleep() function on line 9. To end the program, press Ctrl-C.
Print the Date and Time
The following program prints the current date and time to the LCD:
import I2C_LCD_driver import time mylcd = I2C_LCD_driver.lcd() while True: mylcd.lcd_display_string("Time: %s" %time.strftime("%H:%M:%S"), 1) mylcd.lcd_display_string("Date: %s" %time.strftime("%m/%d/%Y"), 2)
Print Your IP Address
This code prints the IP address of your ethernet connection (eth0). To print the IP of your WiFi connection, change
wlan0 in line 18:
import I2C_LCD_driver import socket import fcntl import struct mylcd = I2C_LCD_driver.lcd() def get_ip_address(ifname): s = socket.socket(socket.AF_INET, socket.SOCK_DGRAM) return socket.inet_ntoa(fcntl.ioctl( s.fileno(), 0x8915, struct.pack('256s', ifname[:15]) )[20:24]) mylcd.lcd_display_string("IP Address:", 1) mylcd.lcd_display_string(get_ip_address('eth0'), 2)
Scroll Text Right to Left Continuously
This program will scroll a text string from the right side of the LCD to the left side and loop continuously:
import I2C_LCD_driver from time import * mylcd = I2C_LCD_driver.lcd() str_pad = " " * 16 my_long_string = "This is a string that needs to scroll" my_long_string = str_pad + my_long_string while True: for i in range (0, len(my_long_string)): lcd_text = my_long_string[i:(i+16)] mylcd.lcd_display_string(lcd_text,1) sleep(0.4) mylcd.lcd_display_string(str_pad,1)
Scroll Text Right to Left Once
The following code slides text onto the screen from right to left once, then stops and leaves a cleared screen.
import I2C_LCD_driver from time import * mylcd = I2C_LCD_driver.lcd() str_pad = " " * 16 my_long_string = "This is a string that needs to scroll" my_long_string = str_pad + my_long_string for i in range (0, len(my_long_string)): lcd_text = my_long_string[i:(i+16)] mylcd.lcd_display_string(lcd_text,1) sleep(0.4) mylcd.lcd_display_string(str_pad,1)
Scroll Text Left to Right Once
This program slides text onto the screen from left to right once, then stops and leaves the first 16 characters of the text string on the screen.
import I2C_LCD_driver from time import * mylcd = I2C_LCD_driver.lcd() padding = " " * 16 my_long_string = "This is a string that needs to scroll" padded_string = my_long_string + padding for i in range (0, len(my_long_string)): lcd_text = padded_string[((len(my_long_string)-1)-i):-i] mylcd.lcd_display_string(lcd_text,1) sleep(0.4) mylcd.lcd_display_string(padding[(15+i):i], 1)
You can create any pattern you want and print it to the display as a custom character. Each character is an array of 5 x 8 pixels. Up to 8 custom characters can be defined and stored in the LCD’s memory. This custom character generator will help you create the bit array needed to define the characters in the LCD memory.
Printing a Single Custom Character
The following code generates a “<” character:
import I2C_LCD_driver from time import * mylcd = I2C_LCD_driver.lcd() fontdata1 = [ [ 0b00010, 0b00100, 0b01000, 0b10000, 0b01000, 0b00100, 0b00010, 0b00000 ], ] mylcd.lcd_load_custom_chars(fontdata1) mylcd.lcd_write(0x80) mylcd.lcd_write_char(0)
Printing Multiple Custom Characters
This program prints a large right pointing arrow (→) to the screen:
import I2C_LCD_driver from time import * mylcd = I2C_LCD_driver.lcd() fontdata1 = [ # char(0) - Upper-left character [ 0b00000, 0b00000, 0b00000, 0b00000, 0b00000, 0b00000, 0b11111, 0b11111 ], # char(1) - Upper-middle character [ 0b00000, 0b00000, 0b00100, 0b00110, 0b00111, 0b00111, 0b11111, 0b11111 ], # char(2) - Upper-right character [ 0b00000, 0b00000, 0b00000, 0b00000, 0b00000, 0b00000, 0b10000, 0b11000 ], # char(3) - Lower-left character [ 0b11111, 0b11111, 0b00000, 0b00000, 0b00000, 0b00000, 0b00000, 0b00000 ], # char(4) - Lower-middle character [ 0b11111, 0b11111, 0b00111, 0b00111, 0b00110, 0b00100, 0b00000, 0b00000 ], # char(5) - Lower-right character [ 0b11000, 0b10000, 0b00000, 0b00000, 0b00000, 0b00000, 0b00000, 0b00000 ], ] mylcd.lcd_load_custom_chars(fontdata1) mylcd.lcd_write(0x80) mylcd.lcd_write_char(0) mylcd.lcd_write_char(1) mylcd.lcd_write_char(2) mylcd.lcd_write(0xC0) mylcd.lcd_write_char(3) mylcd.lcd_write_char(4) mylcd.lcd_write_char(5)
Print Data from a Sensor
The code below will display data from a DHT11 temperature and humidity sensor. Follow this tutorial for instructions on how to set up the DHT11 on the Raspberry Pi. The DHT11 signal pin is connected to BCM pin 4 (physical pin 7 of the RPi).
Temperature is displayed on line 1, and humidity is displayed on line 2:
import RPi.GPIO as GPIO import dht11 import I2C_LCD_driver from time import * mylcd = I2C_LCD_driver.lcd() GPIO.setwarnings(False) GPIO.setmode(GPIO.BCM) GPIO.cleanup() while True: instance = dht11.DHT11(pin = 4) result = instance.read() # Uncomment for Fahrenheit: # result.temperature = (result.temperature * 1.8) + 32 if result.is_valid(): mylcd.lcd_display_string("Temp: %d%s C" % (result.temperature, chr(223)), 1) mylcd.lcd_display_string("Humidity: %d %%" % result.humidity, 2)
For Fahrenheit, un-comment lines 18 and 19, and change the C to an F in line 22. You can also change the signal pin of the DHT11 input in line 15.
By inserting the variable from your sensor into the
mylcd.lcd_display_string() function (line 22 in the code above) you can print the sensor data just like any other text string.
These programs are just basic examples of ways you can control text on your LCD. Try changing things around and combining the code to get some interesting effects. For example, you can make some fun animations by scrolling with custom characters. Don’t have enough screen space to output all of your sensor data? Just print and clear each reading for a couple seconds in a loop.
Let us know in the comments if you have any questions or trouble setting this up. Also leave a comment if you have any other ideas on how to get some cool effects, or just to share your project!
